GARDEN CITY TERMINAL
The single largest and fastest growing
container terminal in North America.
We Move More.
GPA’s 37 weekly containership services, supported by the largest single-operator terminal in the nation at 1,345 acres, provide faster, easier connections to global markets.
Interstate Access
Fast and easy access to 44% of U.S. consumers and manufacturers.
Immediate access to I-16 (East/West) and I-95 (North/South), means key cities and manufacturing points throughout the U.S. Southeast and Midwest may be reached within a one- to two-day drive.
Rail Access
CSX Transportation and Norfolk Southern Railroad provide Class I service and operate on-terminal.
CSX Transportation serves the Chatham Intermodal Container Transfer Facility (ICTF), while Norfolk Southern Railroad calls the James D. Mason ICTF. Both on-terminal ICTF’s are owned and operated by the Georgia Ports Authority. Two- to five-day double-stack rail service is available to inland destinations such as Atlanta, Charlotte, Chicago, Dallas, Memphis, and beyond.
PORT SECURITY
The Georgia Ports Authority Police Department (GPAPD) is the primary law enforcement agency responsible for providing public safety and security on all properties owned and operated by the Georgia Ports Authority (GPA). The department is composed of certified peace officers, security personnel and civilian administrative staff members who work seamlessly to deliver high levels of professional services.
Learn MoreFacility Overview
OVERVIEW
Terminal Owner / Operator | Terminal Owner / Operator |
Terminal Area | 1,345 acres / 544.3 hectares |
Channel Width | 500 ft / 152.4 m |
Channel Project Depth | 42 ft / 12.8 m at MLW |
Future channel Project Depth | 47 ft / 14.3 m at MLW |
Tidal Range | 7.5 ft / 2.3 m |
King’s Island Turning Basin | 1,500 ft x 1,600 ft / 457.2 m x 487.7 m |
Cargo Handled | Containers |
CONTAINER BERTHS
Container Berths | Linear Feet | Linear Meters | Depth Alongside | Dock Height | Apron Width |
---|---|---|---|---|---|
1 | 1,690 | 515 | 42 ft / 12.8m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
2 | 1,158 | 353 | 48 ft / 14.6 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
3 | 1,200 | 366 | 48 ft / 14.6 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
4 | 917 | 280 | 42 ft / 12.8m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
5 | 719 | 219 | 42 ft / 12.8 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
6 | 733 | 223 | 42 ft / 12.8 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
7 | 1,092 | 333 | 42 ft / 12.8 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
8 | 1,092 | 333 | 48 ft / 14.6 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
9 | 1,092 | 333 | 48 ft / 14.6 m at MLW | 15 ft / 4.6 m at MLW | Up to 196 ft / 59.7 mRS |
Total | 9,693 | 2,955 |
CONTAINER CRANES (TOTAL 36)
Container Crane | Manufacturer | Class | Vessel Width Capacity |
---|---|---|---|
10 | Kone | Post-Panamax | 17 Containers across |
11 | Kone | Post-Panamax | 17 Containers across |
12 | Kone | Post-Panamax | 17 Containers across |
14 | Kone | Post-Panamax | 17 Containers across |
16 | Kone | Post-Panamax | 17 Containers across |
17 | Kone | Post-Panamax | 17 Containers across |
18-29 | Kone | Super Post-Panamax | 24 Containers across |
30-33 | Kone | Super Post-Panamax | 24 Containers across |
34-47 | Kone | Super Post-Panamax | 24 Containers across |
CONTAINER CRANES LIFT CAPACITY
Under Spreader Bar | 56 st / 50 lt / 50.8 mt | 72.8 st / 65 lt / 66 mt | 72 st / 65 lt / 65.3 mt | 72 st / 65 lt / 65.3 mt |
Under Cargo Beam | 78.4 st / 70 lt / 71.1 mt | 95.2 st / 85 lt / 86.3 mt | 95.2 st / 85 lt / 86.3 mt | 95.2 st / 85 lt / 86.3 mt |
MAIN HOIST SPEED
Fully Loaded | 246 fpm @ 50 lt 75 mpm | 246 fpm @ 50 lt 75 mpm | 246 fpm @ 50 lt 75 mpm | 246 fpm @ 50 lt 75 mpm |
No Load | 492 fpm / 150 mpm | 492 fpm / 150 mpm | 492 fpm / 150 mpm | 492 fpm / 150 mpm |
Trolley Speed | 500 fpm / 152 mpm | 590 fpm / 180 mpm | 590 fpm / 180 mpm | 590 fpm / 180 mpm |
Gantry Speed | 180 fpm / 54.9 mpm | 180 fpm / 54.9 mpm | 180 fpm / 54.9 mpm | 180 fpm / 54.9 mpm |
Dock Elevation | 0 | 0 | 0 | 0 |
Mean High Water Elevation | -6.98 ft / -2.13 m | -6.98 ft / -2.13 m | -6.98 ft / -2.13 m | -6.98 ft / -2.13 m |
Mean Low Water Elevation | -15.48 ft / -4.7 m | -15.48 ft / -4.7 m | -15.48 ft / -4.7 m | -15.48 ft / -4.7 m |
Bottom Elevation | -57.48 ft / -17.5 m | -57.48 ft / -17.5 m | -57.48 ft / -17.5 m | -57.48 ft / -17.5 m |
Total Lift Height | 180 ft / 54.9 m | 180 ft / 54.9 m | 196 ft / 59.7 m | 212 ft / 64.6 m |
Clear Lift Above Dock | 120 ft / 36.6 m | 120 ft / 36.6 m | 136 ft / 41.4 m | 152 ft / 46.3 m |
BOOM CLEARANCE
Above Dock | 139.25 ft / 42.4 m | 139.8 ft / 42.6 m | 155.8 ft / 47.4 m | 171.8 ft / 52.3 m |
CRANE OVERALL
Height Boom Up | 317 ft / 96.6 m | 374 ft / 111.9 m | 390 ft / 118.8 m | 412 ft / 125.7 m |
Portal Clearance | 45 ft / 13.7 m | 52.2 ft / 15.8 m | 52.2 ft / 15.8 m | 52.2 ft / 15.8 m |
OUTREACH
From Dockface | 145 ft / 44.2 m | 191.8 ft / 58.4 m | 191.8 ft / 58.4 m | 191.8 ft / 58.4 m |
Waterside Rail Setback | 8.3 ft / 2.5 m | 8.3 ft / 2.5 m | 8.3 ft / 2.5 m | 8.3 ft / 2.5 m |
Crane Rail Gauge | 90 ft / 27.4 m | 90 ft / 27.4 m | 90 ft / 27.4 m | 90 ft / 27.4 m |
Backreach | 65 ft / 19.8 m* | 80 ft / 24.3 m | 80 ft / 24.3 m | 80 ft / 24.3 m |
Overall Width | 88.5 ft / 27 m | 88.5 ft / 27 m | 88.5 ft / 27 m | 88.5 ft / 27 m |
(Bumpers Compressed) | ||||
Clearance Between Legs | 55 ft / 16.8 m | 60 ft / 18.3 m | 60 ft / 18.3 m | 60 ft / 18.3 m |
LIQUID BULK BERTH
Linear Feet | 600 |
Linear Meters | 183 |
EQUIPMENT
Rubber-tired Gantries | (146)* 45-56 st / 40-50 lt Capacity |
Five-high Loaded Toplifts | (5) 80,000 lb / 36,287 kg Under Spreader Capacity |
Seven-high Empty Stackers | (40) 18,000 lb / 8,165 kg Under Spreader Capacity |
Forklifts | (44) 11,000 lb-50,000 lb / 4,990 kg-22,680 kg Capacity With Accessory Attachments |
Over-height Container Crane Attachment | (9) 45 st / 40 lt Capacity Speed Loader |
Reefer Wheeled Plugs | 482 |
Reefer Racks | (119) CB-2, 34 Racks with Capacity of 816 Slots; CB-5/6, |
Reefer Rack Plugs | 2,856 |
28 Racks with Capacity of 672 Slots; CB-8, 40 Racks with a Capacity of 960 Slots | |
CB-1: 17 Racks with Capacity of 408 Slots | |
Rail Mounted Gantry Cranes | Four set to be operational in 2020 |
WAREHOUSING | AREA | RAIL SIDING |
---|---|---|
83-A | 402,000 ft2 / 37,347 m2 | 1400 ft / 427 m |
83-B | 400,800 ft2 / 37,236 m2 | 1400 ft / 427 m |
Warehouse 27/U.S. Customs & Boarder Protection (USCBP) | 130,000 ft2 / 12,077 m2 | 578 ft / 176 m |
CFS 1 | 87,992 ft2 / 8.175 m2 | N/A CFS 2 |
CFS 2 | 103,224 ft2 / 9,590 m2 | N/A CFS 2 |
Total | 1,124,016 ft2 / 104,425 m2 | 3,378 ft / 1,030 m |
CONTAINER FIELD | CB1 | CB2 | CB3 | CB4 | CB5 | CB6 | CB7 | CB8 | MASON EMPTY YARD |
---|---|---|---|---|---|---|---|---|---|
Paved Area (acres) | 47 | 77 | 29 | 70 | 34 | 48 | 56 | 70 | 40 |
Paved Area (hectares) | 19.0 | 31.2 | 11.7 | 28.3 | 13.8 | 19.4 | 22.7 | 28.3 | 16.2 |
MASON ICTF**
Working Tracks | (5) 2,500 ft / 762 m totaling 15,000 ft / 3,810 m |
Storage Tracks | (3) 2,500 ft / 762 m totaling 7,500 ft / 2,286 m |
Facility Area | 160 acres / 65 hectares |
Paved Area | 2.5 acres / 1 hectares |
CHATHAM ICTF
Working Tracks | (3) 2,000 ft / 609 m totaling 6,000 ft / 1,829 m |
Storage Tracks | (6) 2,500 ft / 762 m totaling 10,000 ft / 3,048 m |
Facility Area | 18 acres / 7.3 hectares |
Paved Area | 2.5 acres / 1 hectares |
INTERCHANGE LANES
Gate 3 | 15 Lanes with 10 Pre-check Lanes; 2-lane entry portal with OCR-Smart Cameras and RF-Reading Equipment to electronically capture data from arriving trucks |
Gate 4 | 19 Lanes with 13 Pre-check Lanes; 6-lane entry portal with OCR-Smart Cameras and RF-Reading Equipment to electronically capture data from arriving trucks |
Gate 8 | 16 Lanes with 8 Pre-check Lanes; 2-lane entry portal with OCR-Smart Cameras and RF-Reading Equipment to electronically capture data from arriving trucks |
Total | 50 Lanes with 31 Pre-check Lanes; 12 Portal Approach Lanes |
PORT SERVICES
Interstate Access: | Garden City Terminal is within 6 miles (10 km) of Interstate 16 (East/West) and 5.8 miles (9 km) of Interstate 95 (North/South). |
Rail Services: | CSX Transportation and Norfolk Southern Railroad provide Class I service and operate on-terminal. CSX Transportation serves the Chatham Intermodal Container Transfer Facility (ICTF), while Norfolk Southern Railroad calls the James D. Mason ICTF. Both on-terminal ICTF’s are owned and operated by the Georgia Ports Authority. Two- to five-day double-stack rail service is available to inland destinations such as Atlanta, Charlotte, Chicago, Dallas, Memphis, and beyond. |
PORT SECURITY
Federal regulations require all regular port users requesting unescorted access to GPA’s restricted terminals be properly credentialed (TWIC and GPA credential) and be authorized entry at an established facility access control point prior to entering the terminal. Restricted marine terminal perimeters are fenced, illuminated during hours of darkness, and patrolled regularly. Terminals are actively monitored, 24/7/365, utilizing a combination of modern security technology applications and personnel assets. |
